Follett Symphony 25CI400A - Dispenser Parts - SensorSAFE Models; Chute and Splash Panel Parts (S;N D61292+)

38 25CI400A/W • 25HI400A • 50CI400A/W • 50HI400A
Dispense chute and splash panel areas (SensorSAFE models) — Serial Number D61292
and above
9
8
11
8
14
7
15
12
2
3
4
1
5
13
6
10
16
Reference Description Part #
1 Bracket, water solenoid 00987875
2 Tube, water station 00187682
3 Fitting, outlet, 1/8" MPT x 3/8" comp 502262
4 Fitting, inlet, 1/8" MPT x 1/4" comp 502246
5 Solenoid valve, water, 120 V, 60Hz 502243
6 Chute, ice (with Agion) 00984831
7 Splash panel, SensorSAFE dispense with drain pan (includes 2 lenses) 00981365
7 Splash panel, SensorSAFE dispense with drain pan, ice only (includes 1 lens) 00981381
7 Splash panel, SensorSAFE dispense, no drain pan (includes 2 lenses) 00981373
7 Splash panel, SensorSAFE dispense, no drain pan, ice only (includes 1 lens) 00981399
8 Sensor, ice or water dispense 00195982
9 Clean switch, SensorSAFE (includes boot) 502359
10 Boot, clean switch button (mounts on 502359 switch) 501841
11 Bracket, water valve 00958793
12 Chute, water (with Agion) 00984898
13 Elbow, 1/4" 00121699
14 Lens, sensors 00977983
15 Screw, bracket 00982421
16 Screw, valve 203227
Not shown Tubing, water station, thermoplastic, 1/4" OD (sold by the foot) 502079
