113
Backup Folders in your USB Flash Drive
The following folders are automatically created in a USB flash drive when backing up through
the USB flash drive.
/ (Root)
CLIP1
CLIP2
Used for uploading backup movie clips (sequential files) to
STILL1-2.
Each folder should contain only one clip.
STILL1
STILL2
Used for uploading backup image files to STILL1-2.
Each folder should contain only one still image file.
STILL_IN01
STILL_IN08
Used for uploading backup image files for INPUT STILL
Each folder should contain only one still image file.
* If a subfolder in the USB stick is accidentally erased, set BACKUP to OFF then ON in the menu (see
below). A new subfolder will be created.
12-3-2. Setting Automatic Backup to ON
(1) Insert a USB memory stick for backup into the USB port on the switcher.
(2) Press MENU, then STILL in the SELECT/KEYPAD block to open the [STILL] menu.
(3) Go to PAGE 3.
(4) Turn F3 to set BACKUP ON to enable automatic backup. If set to OFF, backup is
disabled.
STILL :STILL : FUNC :BACKUP : : 3/6
BACKUP :=STIL1 : <LOAD : =ON : :
Automatic backup is enabled or disabled for all STILL1-2, INPUT_STILL1-8 and CLIP1-2,
images and cannot be set individually for each file.
12-3-3. Manually Loading Backup Data
(1) Insert the USB memory stick in which the backup is stored into the USB port.
(2) Go to [STILL] menu PAGE 3.
(3) Turn F1 to select a still, input still or clip to be backed up.
(4) Turn F2 to select LOAD. Then press F2 to load the backup data.
STILL :STILL : FUNC :BACKUP : : 3/6
BACKUP :=STIL1 : <LOAD : =ON : :
