18. System Setup Settings
18-1. Selecting System Signal Format
(1) Press MENU in the SELECT/KEYPAD block, then press SETUP to display the SETUP top
menu.
(2) Turn F1 to select SYSTEM, then press F1 or the page down button to open the [SETUP -
SYSTEM] menu.
(3) Turn F1 to select FORMAT, then press F1 or the page down button to open the [SETUP -
SYSTEM - FORMAT] menu.
SETUP :>FORMAT >REF I/O >ARCNET >ETHERNET
SYSTEM :>RS-422 >TIME >INIT >REBOOT
(4) Turn F1 to select the TV format, then press F1.
Turn F3 to select the aspect ratio, then press F3.
SYSTEM : FORMAT :ASPECT :SW TMNG: 1/1
FORMAT : =1080/59.94i : =16:9 : =ANY :
(5) Press the page up button to go back to the [SETUP - SYSTEM] menu.
(6) Turn F1 to select REBOOT and then press F1. Press the ENTER button in the
SELECT/KEYPAD block to reboot the system.
SETUP :>FORMAT >REF I/O >ARCNET >ETHERNET
SYSTEM :>RS-422 >TIME >INIT >REBOOT
(7) The selected system format is applied to the switcher after rebooting.
18-2. Crosspoint Switch Timing
The switcher can be set when and where crosspoints are switched.
(1) Open the [SETUP - SYSTEM - FORMAT] menu. (See the procedure above.)
(2) Turn F4 to set the switcher timing at the SW TMNG item.
SYSTEM : FORMAT :ASPECT :SW TMNG: 1/1
FORMAT : =1080/59.94i : =16:9 : =ANY :
Signal Format
Setting
Description
1080i/59.94, 50
525/60
625/50
ODD
Switches crosspoints in odd fields.
EVEN
Switches crosspoints in even fields.
ANY
Switches crosspoints any time commands are issued.
720p/59.94, 50
No1
Switches crosspoints in odd frames.
No2
Switches crosspoints in even frames.
ANY
Switches crosspoints any timecommands are issued.
1080PsF/29.97,
25, 24, 23.98
---
Switches crosspoints at the same time regardless of
setting.
