Appendix 1. Available Files for Saving and/or Loading
Menu Setting Files and Image Files (via USB flash drive or Ethernet connection)
File Extension
File Name (*1)
File Data Description
all
DATA.all
System settings and all wipe, event and macro data
sys
HVSXT100.sys
System settings
mem
EVENT.mem
All event memory data
mcr
MACRO.mcr
All macro data
jpg (*2)
JPEG files (standard RGB)
JPEG sequential files
Stored still in JPEG format
tga (*2)
*.tga
TARGA files (uncompressed RGB)
TARGA sequential files
STILL1.tga～STILL2.tga
Stored still in TARGA format
bmp (*2)
BITMAP files (uncompressed RGB)
BITMAP sequential files
Stored still in BITMAP format
Note that file names are limited to max. 16 characters in length (ASCII code).
(*1) Files are automatically named to their correct name as shown in the table above when saving to
USB flash drive.
(*2) When loading a jpeg, targa or bitmap file from USB flash drive, you can select a centered or tiled
format as well as a normal one. In such case, a centered or tiled format image file is saved to
STILL as a jpg, tga or bmp file.
Factory Tested USB Flash Drives
Manufacturer
Series Name
Model Name
SanDisk
Cruzer micro, Cruzer mini Series
SDCZ2-256
I/O DATA
TB-ST Series
ToteBag
Transcend
JetFlash150 Series
TOSHIBA
TransMemory Series
U2B-256MT
