FOR-A HVS-XT110 - Page 171

171
 TALLY function
FUNCTION setting
Description
KEY1 ON TLY
KEY2 ON TLY
DSK1 ON TLY
DSK2 ON TLY
Outputs tally signal when KEY or DSK is on the
background video.
FAN ERROR ALARM
Outputs power or fan alarm.
XT100
PS1-2 ERROR ALARM
ALL ALARM
RED TALLY-BLACK
Outputs a red tally when the specified signal is sent to the
red (tally color) bus.
XT100
RED TALLY-IN01-08
XT110
RED TALLY-IN01-12
RED TALLY-STIL1-2
RED TALLY-STILK1-2
RED TALLY-MATT1-2
RED TALLY-CKFIL
RED TALLY-CKKEY
RED TALLY-EFF1-2
RED TALLY-PGM
RED TALLY-PREV
RED TALLY-CLN
GREEN TALLY-BLACK
Outputs a green tally when the specified signal is sent to
the green (tally color) bus.
XT100
GREEN TALLY-IN01-08
XT110
GREEN TALLY-IN01-12
GREEN TALLY-STIL1-2
GREEN TALLY-STILK1-2
GREEN TALLY-MATT1-2
GREEN TALLY-CKFIL
GREEN TALLY-CKKEY
GREEN TALLY-EFF1-2
GREEN TALLY-PGM
GREEN TALLY-PREV
GREEN TALLY-CLN
AUX1 to 8 TRANS ENABLE
Outputs tally signal when AUX transition is enabled.
