5100ex Calibration Manual
Description of Calibration Values
2
Entering the Calibration Menu
The Calibration menu is entered by pressing the Calib button in the Main Menu. Unlike the
Material Select, Unload, Data, and Version Menus, the Calibration Menu requires the entry of an
Access Code before it will appear. You can insert a USB supervisor key instead of entering the
access code to access the Calibration Menu.
To enter Calibration using Access Code:
1. While the system is in Standby, press the Menu button on the Operation Screen.
2. Press the Calibration menu button. The Access Code window will appear, as shown in
Figure 1.
Figure 1: The Access Code Window
3. Enter the access code using the up and down arrow buttons on screen. Use the left and
right arrows to move to a different digit. You may also tap a number cell to highlight it.
When entering the Access Code, the buttons have the following functions:
Input Function
Increase the highlighted digit by 1.
Decrease the highlighted digit by 1.
Highlight the previous digit.
Highlight the next digit.
Enter Access Code.
Return to the Main menu.
