5100ex Calibration Manual
Description of Calibration Values
22
Most of the functions inside the Dust Control menu operate the same as those in the Anti-Ice
menu. Refer to the above section for information on setting each of these parameters. Dust
control does have the following additional controls for Boom Width setup.
Boom Width
Entering the Boom Width submenu allows the boom widths to be set for each boom.
Note that the Left and Right booms are only available when the Direct Liquid system is
set to Multi-Lane.
Herbicide
The Herbicide menu allows you to configure settings for the direct material. If Config →
Application Mode is set to Granular or Herbicide is not selected as one of the available direct
liquid types in the Direct Type options, this menu will be disabled.
The spreading units for herbicide are:
Type English Units Metric Units
Herbicide Gal/Ac L/HA
Most of the functions inside the Herbicide menu operate the same as those in the Anti-Ice menu.
Refer to the above section for information on setting each of these parameters. Herbicide does
have the following additional controls for Boom Width setup.
Boom Width
Entering the Boom Width submenu allows the boom widths to be set for each boom.
Note that the Left and Right booms are only available when the Direct Liquid system is
set to Multi-Lane.
Inputs/Outputs
The Inputs/Outputs menu allows you to configure settings for the input and aux output wires on
the primary spreader harness.
Inputs
The Inputs submenu allows you to configure the settings for the input wires.
Input 1, Input 2, Input 3, Input 5, Input 6
The Input menu item allows you to set what 5100ex function will run when the
corresponding Input wire is grounded. The default value is Off. If Config →
Auger → Options → Two Position Gate is Enabled, Input 1 and Input 2 will be
used by that feature and cannot be adjusted here.
Function Operation
Off The input does nothing.
Blast The input will be used to turn on and off the spreader blast
function remotely.
Standby The input will be used to activate and deactivate the spreader
output remotely.
Low Material The input will be used to activate an alarm when the granular
material is running low or empty and the spreader is
attempting to apply granular material
Low Prewet The input will be used to activate an alarm when the liquid in
the prewet liquid tank is low.
Conveyor Stall The input will be used to indicate a Conveyor Stall condition.
