5100ex Calibration Manual
Description of Calibration Values
21
 =
 × 1000

Full Speed Displacement Rate
The Full Speed Displacement Rate menu item allows you to set the maximum amount of
direct liquid displaced by the direct pump in a single minute when running at the direct
pump maximum speed. The default value is 100.0 gallons per minute or 378.5 liters per
minute. If this value is not known it can be determined using the built in AutoCal feature.
For more information see see AutoCalibration of a Direct Liquid on page 42.
Number Of Set Rates
The Number Of Set Rates menu item changes how many set rates will be available to the
driver during operation. If a set rate is configured with non-default settings and then is
disabled with this menu item, its custom settings will not be cleared. The default value is
10.
Set Rates
Entering the Set Rate submenu presents a list of all the custom set rates available for the
direct material.
Set Rate 1, Set Rate 2, Set Rate 3, etc.
The Set Rate menu item sets which gallons per mi or liters per km setting will be
output when the user chooses the corresponding set rate. The default values are
shown in the table below.
Set Rate Default English Rate
(Gallons per Mile)
Default Metric Rate
(Liters per
Kilometer)
Set Rate 1 20.0 47.0
Set Rate 2 25.0 58.8
Set Rate 3 30.0 70.6
Set Rate 4 35.0 82.3
Set Rate 5 40.0 94.1
Set Rate 6 45.0 105.8
Set Rate 7 50.0 117.6
Set Rate 8 55.0 129.4
Set Rate 9 60.0 141.1
Set Rate 10 65.0 152.9
Blast Rate
The Blast Rate menu item sets the amount of direct material the spreader will
spread when it is activated in Blast mode. The default value is 65 gallons per
mile (152.9 liters per mile).
Dust Control
The Dust Control menu allows you to configure settings for the direct material. If Config →
Application Mode is set to Granular or Dust Control is not selected as one of the available direct
liquid types in the Direct Type options, this menu will be disabled.
The spreading units for dust control are:
Type English Units Metric Units
Dust Control Gal/Sq Yd L/M
2
