5100ex Calibration Manual
Description of Calibration Values
23
Oil Level The input will be used to indicate an Oil Level Warning.
Oil Temp The input will be used to indicate an Oil Temperature Warning
Filter Bypass The input will be used to indicate a Filter Bypass error
condition.
Low Direct The input will be used to activate an alarm when the liquid in
the direct liquid tank is low.
Low Liquid The input will be used to activate an alarm when the liquid in
the direct liquid tank or prewet liquid tank is low.
Outputs
The Outputs submenu allows you to configure the settings for the aux output wires. If
5150 mode is enabled or Config → Application Mode is set to Gran/Dir 3 Lane or Direct 3
Lane, this menu will be disabled.
Output 1, Output 2
The Output menu item allows you to set what 5100ex function will activate the
aux output. The default value is Off.
Function Operation
Off The aux output does nothing.
Auger On The aux output will be on when the auger is running.
Auger Forward The aux output will be on when auger forward is active.
Auger Reverse The aux output will be on when auger reverse is active.
Prewet The aux output will be on when prewet is active.
Prewet On The aux output will be on when the prewet pump is running.
Prewet Divert The aux output will be on when auger reverse and prewet are
active.
Standby The aux output will be on when the system is not in standby.
Direct The aux output will be on when direct is active.
Direct On The aux output will be on when the direct pump is running.
Hoist/Plow
The Hoist/Plow menu allows you to configure settings related to the operation of the hoist and
plow on 5150ex systems. This menu is only available on 5150ex systems.
Options
The Options item allows you to configure which of the hydraulic functions can be
activated using the unit. This feature is only available on 5150ex systems. The default
value is Hoist & Plow.
Option Description
Hoist & Plow The system will contain switch functions and outputs for the
hoist up, hoist down, plow up, plow down, plow left and plow
right hydraulic functions.
Hoist The system will contain switch functions and outputs for the
hoist up, and hoist down hydraulic functions.
Plow The system will contain switch functions and outputs for the
plow up, plow down, plow left and plow right hydraulic
functions.
