5100ex Calibration Manual
Description of Calibration Values
4
Application
Mode
Operation
Granular
The system will only run in granular mode.
The Mode menu item in the main menu will be disabled.
Gran/Dir 1
Lane
The system can run in granular mode or direct mode.
The user can swap between granular and direct modes
using the Mode menu item in the main menu.
The lane switches will be disabled.
Gran/Dir 3
Lane
The system can run in granular mode or direct mode.
The user can swap between granular and direct modes
using the Mode menu item in the main menu.
The user can turn on and off lanes by using the lane
switches.
Aux Output 1 and Aux Output 2 are used by the lanes
and cannot be used for other purposes.
Direct 1
Lane
The system will only run in direct mode.
The Mode menu item in the main menu will be disabled.
The lane switches will be disabled.
Direct 3
Lane
The system will only run in direct mode.
The Mode menu item in the main menu will be disabled.
The user can turn on and off lanes by using the lane
switches.
Aux Output 1 and Aux Output 2 are used by the lanes
and cannot be used for other purposes.
Units
The Units menu item changes the type of measurement system the vehicle uses for
operation. The available options are English and Metric. The default value is English.
PWM Mode
The PWM Mode setting adjusts the PWM output to allow for operating coils with different
resistance values. Normal PWM mode should be used with 6 ohm valve coils, while
Profile 1 PWM mode should be used with 3 ohm valve coils. The default value is Normal.
Valve Freq
The Valve Freq menu item changes the frequency the 5100ex uses to run its valves. The
frequency can be set to any value between 50Hz and 250Hz. The default value is 50 Hz.
Prewet
The Prewet menu item enables or disables Prewet application for the entire system. The
default value is Disabled.
Event Logging
The Event Logging menu item selects the Event Logging format that will be used with the
system. The available options are Disabled, PreCise, and AVL. The default value is
Disabled. For more information on Event Logging, see page 28.
Model Code
The Model Code menu item is used by the factory to configure the unit.
