Introduction | 9
2.2 Technical Specifications
Form 3
Printer
Resin Cartridge Form 3
Resin Tank
Form 3
Build Platform
Shipping
Dimensions
57×51×69 cm
(22.5×20×27 in)
24×20×8 cm
(9.5×8×3 in)
35×30×8 cm
(14×11.8×3.3 in)
18×17×8 cm
(7×6.75×3 in)
Shipping Weight 22.7 kg (50 lb) 1.5 kg (3.3 lb) 1.4 kg (3.1 lb) 0.67 kg (1.5 lb)
Product Weight 17.5 kg (38.6 lb) 1.35-1.6 kg
(3-3.5 lb)
0.8 kg (1.8 lb) 0.65 kg (1.4 lb)
3D Printing Technology Low Force Stereolithography (LFS)
Minimum Dimensions for
Convenient Access
Width: 40 cm (15.5 in)
Depth: 53 cm (21 in)
Height: 78 cm (30.5 in)
Weight 17.2 kg (37.9 lb)
Operating Temperature Auto-heats to 35 °C (95 °F)
Temperature Control Air heated print chamber
Power Requirements 100–240 V ~
2.5 A
50/60 Hz
220 W
Laser Specifications 1 Light Processing Unit
EN 60825-1:2014 certified
Class 1 Laser Product
405 nm violet laser
250 mW laser
Laser Spot Size (FWHM) 85 microns (0.0033 in)
Radiation Information The Form 3 is a Class 1 Laser product. Accessible radiation is within
Class 1 limits.
Connectivity Wi-Fi, Ethernet, and USB
Ethernet Connectivity RJ-45 Ethernet (10BASE-T/100BASE-TX/1000BASE-T) LAN Port
Connect with an Ethernet cable (not included): minimum Cat5, or
Cat5e or Cat6 for 1000BASE-T.
Wi-Fi Connectivity Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz, 5 GHz
Supported security: WPA/WPA2
Sound Emission Does not exceed 70 dB(A).
Printer Control Interactive touchscreen
Resin Fill System Automated
Build Volume 145×145×185 mm
5.7×5.7×7.3 in
Supports Auto-Generated
Removable
