P a g e | 21
Use protective plastic gloves to keep oil off skin, dispose of oil and filter in an
environmentally responsible manner.
1. The filter housing is accessed via the left side panel. Thoroughly clean around
filler housing before removing to help prevent debris getting into oil.
2. Unscrew filter housing body, remove filter element and allow to drain for 15
minutes before disposal.
3. Screw on and tighten filter body with new filter into filter housing.
Oils, Fluids and Lubricants.
Hydraulic Oil: ISO VG 46.
It is advised that the oil is checked and topped up to the RED LINE on the sight
glass, when the machine is cold and on a flat surface.
Gearbox Oil: SAE90 ā 0.75 Litre
Grease: Lithium EP2 General Purpose.
