Item No Part No Description Quantity
1 12-12-1104 M16 x 110Lg 8.8 Hex Head bolt 1
2 12-14-019 M16 Spring washer DIN 128 1
3 12-14-005 M16 Washer ISO 7089 3
3a 10mm Spacer between 3 and 8 1
4 12-11-011 6304 2RS Deep groove ball bearing 52 OD, 20 ID, 15 wide 2
5 12-01-036 Flat idler pulley-2x 17 V belt 1
6 12-01-024 Flat idler pulley shaft-2x 17 V belt 1
7 12-13-005 M16 nyloc nut ISO 7040 1
8 12-19-062 Tensioner slide fab assy 1
