FORST PT6 - Chipping Chamber Assembly - Bottom Feed Roller Cover

P a g e | 29
Chipping chamber assembly - Bottom feed roller cover.
TOP
Item No Part No Description Quantity
1 12-12-504 M10 x 20Lg 8.8 Hex Head screw 2
2 12-14-010 M10 Spring Washer DIN 128 2
3 12-14-009 M10 Washer ISO 7089 2
4 12-03-045 Feed roller cover 1
