16. Technical Specifications
Tuner & Demodulator
Input Connector F-Type, Female, IEC 169-24
Input Frequency Range 950MHz ~ 2150 MHz
RF Input Signal Level -65dbm ~ -25dbm
LNB Power & Polarization Vertical: +12V ~ +14V
Horizontal: +17V ~ +19V
Current: Max.500mA with overload protection
22KHz Tone Frequency: 22KHz, +/-4KHz
Amplitude: 0.6V, +/-0.2V
DiSEqC Control DiSEqC 1.0, 1.2, 1.3 compatible
Demodulation QPSK & 8PSK
Input Symbol Rate DVB S: 2~45Ms/s
DVB S2: 10~30Ms/s
FEC Code Rate DVB S: 1/2, 2/3, 3/4, 5/6, 7/8
DVB S2(QPSK) : 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9,
9/10
DVB S2(8PSK) : 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
MPEG Transport Stream A/V Decoding
Transport Stream According to ISO / IEC 13818-1
Video Resolution 1920x1080i, 1280x720p, 720x576p, 720x576i
Input Rate Max. 15MB/s
Video MPEG2 MP@HL
, MPEG AVC/H.264 HP@L4
Audio ISO / IEC 13818-3 Layer I & II
Audio Mode Single/Dual Channel
Audio Sampling Frequency 32 / 44.1 / 48KHz
Main System
Main Processor STi7100
Graphic(MPEG) & System Memory 64Mbytes + 64Mbytes
Flash Memory 8Mbytes
EEPROM 8Kbytes
A/V & Data Input/Output
Video TV-Scart (CVBS out, S-Video out)
VCR –Scart (CVBS in/out, RGB in)
RCA Jack(CVBS out),Component Jack(YpbPr out)
Din Jack(S-Video out)
Audio TV-Scart(L/R out)
VCR-Scart(L/R in/out)
RCA Jack(L/R out, Digital audio out)
Optical Jack(Digital audio out)
Digital A/V Output HDMI Digital A/V Output
Serial Port Transfer rate 115200bps
USB A type USB 2.0 HOST (Selectable one of Front or Rear)
Front Panel
KEYS (8 Button) AC Power, Ch Up/Down, Volume Up/Down, Menu,
OK, Back
VFD ( 10Digit Alpha Numeric) Channel Numbers, Name and Time
PCMCIA 2Slot Common Interface
USB 2.0 Host USB A type connector
