Foscam R2 User Manual

77
Video
Image Compression
H.264
Resolution
1080P(1920x1080),720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
manual Pan/Tilt Angle
Horizontal:300° & Vertical: 100°
Audio
Input/Output
Supports two-way audio
Built-in Mic & Speaker
Audio Compression
PCM/G.726
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE802.11b/g/n
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security
WEP, WPA, WPA2
Wireless Setup
Supports EZLink wireless setup
Network Protocol
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、DDNS、
UPnP、RTSP、WPS、ONVIF
Remote Access
P2P, DDNS
System
Requirements
Operating System
Microsoft Windows XP, 7, 8;Mac OS;iOS
、
Android
Browser
IE8 and above version;Firefox;Chrome;Safari.
Other
Features
Motion Detection
Alarm via E-Mail, upload alarm snapshot to FTP
WDR
Improve image clarity in complex scenario
Magic Zoom
Picture zoom function
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Storage
64G Micro SD card, local and FTP storage
Reset
Reset button is available
Power
Power Supply
DC 5V/2.0A
Power Consumption
＜6W
Physical
Dimension (LxWxH)
74x74x119mm(2.9x2.9x4.7in)
Net Weight
290g(0.6lb)
Environment
Operating
Temperature
-10°C ~ 50° (14°F ~ 122°F)
Operating Humidity
20% ~ 85% non-condensing
Storage Temperature
-20°C ~ 60° (-4°F ~ 140°F)
Storage Humidity
0% ~ 90% non-condensing
Certification
CE, FCC, RoHS

Foscam R2 Specifications

General

Type	IP security camera
PTZ control	Yes
Antenna type	External
Antennas quantity	1
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Cube
Mounting type	Desk
Product color	White
Full HD	No
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Night vision distance	8 m
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Interface	RJ-45
Power over Ethernet (PoE)	-
Power consumption (typical)	4.8 W
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Width	70 mm
Height	120 mm
