Foscam R2 User Manual

78
ITEMS
R4
Image Sensor
Sensor Type
1/3'' CMOS
Display Resolution
2560x1440 (4.0 Megapixels), 2304x1296 ( 3.0 Megapixels)
Frame Rate
25fps
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f:4.0mm,F:2.1
Angle of View
Horizontal:67°
Diagonal : 75°
Night Vision
13pcs IR-LEDs, IR Range up to 8m(26ft)
Video
Image Compression
H.264
Resolution
2560x1440 (4.0 Megapixels), 2304x1296 ( 3.0 Megapixels)
，
1080P(1920x1080),720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
manual Pan/Tilt Angle
Horizontal:300° & Vertical: 100°
Audio
Input/Output
Supports two-way audio
Built-in Mic & Speaker
Audio Compression
PCM/G.726
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE802.11b/g/n
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security
WEP, WPA, WPA2
Wireless Setup
Supports EZLink wireless setup
Network Protocol
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、DDNS、
UPnP、RTSP、WPS、ONVIF
Remote Access
P2P
System
Requirements
Operating System
Microsoft Windows XP, 7, 8;Mac OS;iOS
、
Android
Browser
IE8 and above version;Firefox;Chrome;Safari.
Other
Features
Motion Detection
Alarm via E-Mail, upload alarm snapshot to FTP
WDR
Improve image clarity in complex scenario
Magic Zoom
A Magic digital zoom function rivaled Optical zoom
User Accounts
Three levels user role

Foscam R2 Specifications

General

Type	IP security camera
PTZ control	Yes
Antenna type	External
Antennas quantity	1
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Cube
Mounting type	Desk
Product color	White
Full HD	No
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Night vision distance	8 m
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Interface	RJ-45
Power over Ethernet (PoE)	-
Power consumption (typical)	4.8 W
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Width	70 mm
Height	120 mm
