Fourgroup Full-App 2 - 13. GSM MODEM SETTING; Phone Number 2 Configuration; Phone Number 3 Configuration; GSM Connection Test Procedure

34
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
Phone nr.2
+XXXXXXXXXX
The parameter “Phone nr.2” will set the second (3 in total) phone number to send the SMS
messages for the status and alarms as well as the phone number allowed to remotely control
the various parameter settings. The number needs to be entered with international prefix (for
example, +44…..) without any spaces.
Factory default setting: +0000000000.
Phone nr.3
+XXXXXXXXXX
Phone nr.2
+XXXXXXXXXX
Connection Test
SMS number 1
The parameter “Phone nr.3” will set the third and last phone number which to send the SMS
messages for the status and alarms as well as the phone number allowed to remotely control
the various parameter settings. The number needs to be entered with international prefix (for
example, +44…..) without any spaces.
Factory default setting: +0000000000.
Connection Test
SMS number 1
Telefono n.3
+XXXXXXXXXX
Connection Test
SMS number 2
Connection Test
SMS number 1
The parameter “Connection Test SMS number 1” will verify that the communication between
the modem GSM and the “Phone nr.1” is working. To verify it, press the button
which will
send an SMS message immediately from the modem GSM. The text of the message is described
in setting “Station Name”.
Connection Test
SMS number 2
Connection Test
SMS number 1
Connection Test
SMS number 3
Connection Test
SMS number 2
Similarly to the previous parameter, “Connection Test SMS number 2” will verify that the
communication between the modem GSM and the “Phone nr.2” is working. To verify it, press
the button
which will send an SMS message immediately from the modem GSM. The text of
the message is described in setting “Station Name”.
Connection Test
SMS number 3
Connection Test
SMS number 2
Station Name
XXXXXXXXXXX
The parameter “Connection Test SMS number 3” will verify that the communication between
the modem GSM and the “Phone nr.3” is working. To verify it, press the button
which will
send an SMS message immediately from the modem GSM. The text of the message is described
in setting “Station Name”.
NOTE: when the setting to enable/disable the modem GSM is changed (change of parameter “Enable
Modem”
)
it is necessar
y
to exit the
p
ro
g
rammin
g
and re-enter
p
rior to test the connections.
NOTE: the GSM card has an LED to verify the network operator presence (see chapter “GSM” on page 40).
