Foxconn 45CS - Layout

4
1
1. Clear CMOS Jumper
2. Front Audio Connector
3. SPDIF_OUT Connector
4. Front USB Connectors
5. PCI Slot
6. South Bridge: Intel® ICH7
7. Front Panel Connector
8. SATA Connectors
9. 24-pin ATX Power Connector
10. DDR2 DIMM Slot
11. North Bridge: Intel® 945GC
12. CPU
13. TPM Connector
14. IrDA Connector
1-2 Layout
Note : The above motherboard layout is for reference only, please refer to the physical
motherboard for detail.
2
8
9
1
11
12
13
14
4
3
5
6
7
10
