PC Health Status
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
This function works only when your operating system is supporting ACPI.
The CPU/System temperature are automatically detected and displayed by the system.
The System fan speed are automatically detected and displayed by the system.
The current voltages are automatically detected and displayed by the system.
This option is used to enable or disable smart fan function.
Off Temperature
It allows you set a temperature value from which smart fan stops its operation.
PWM Start TemperatureStart TemperatureTemperature
It allows you set a temperature value from which smart fan starts its operation.
Start PWM Value
It allows you to set an initial PWM value to drive the fan when the temperature reaches Start
value and smart fan begins its operation. The higher PWM value can achieve the faster fan
speed.
Slope PWM Value
The slope controls the PWM value being stepped up or down versus temperature changes.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
PC Health Status
CPU Temperature :56:56
o
C/132
o
F
System Temperature :40
o
C/104
o
F
System Fan Speed :N/A DisabledDisabled
50
o
C/122
o
F
CPU Core :1.136 V 5555
o
C/131
o
F
DRAM Voltage :1.760 V 60
o
C/140
o
F
+3.30V :3.376 V 6565
o
C/149
o
F
+5.00V :5.107 V 70
o
C/158
o
F
+12.0V :12.096 V 75
o
C/167
o
F
o
C/176
o
F
85
o
C/185
o
F
90
o
C/194
o
F
F9:Optimized Defaults
Options
To Next Page
