Fox Central Control Unit
► Super BIOS Protect
To protect the system BIOS from virus attack, there is a BIOS write-protection mechanism
provided. Super BIOS Protect function protects your BIOS from being affected by viruses, e.g.
CIH.
► Smart BIOS / Fox Intelligent Stepping / Voltage Options / CPU Configuration
Press <Enter> to go to its submenu.
Smart BIOS
► Smart Power LED
Smart Power LED is a feature built on your motherboard to indicate different states during
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
Fox Central Control Unit
Super BIOS Protect [Disabled] Help Item
► Smart BIOS [Press Enter]
► Fox Intelligent Stepping
[Press Enter]
► Voltage Options
[Press Enter] Disabled
► CPU Conguration [Press Enter]
Enabled
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Disabled]
Options
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
Smart BIOS
Smart Power LED [Disabled] Help Item
Smart Boot Menu [Enabled]
Current CPU Speed : 2600MHz, NB CLK: 2000MHz
Current DRAM Clock : 800 MHz, N/A Disabled
Enabled
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Disabled]
Options

Foxconn A74ML 3.0 Series Specifications

General

Form Factor	Micro ATX
Memory Type	DDR3
Memory Slots	2 x DIMM
Maximum Memory	8 GB
Storage Interface	4 x SATA 3Gb/s
PS/2	1 x PS/2 Keyboard, 1 x PS/2 Mouse
Video Ports	1 x VGA
Dimensions	244mm x 244mm
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	Realtek ALC662 6-channel HD Audio
LAN	10/100 Ethernet
Power Pin	24-pin ATX, 4-pin ATX 12V
Expansion Slots	1 x PCIe x16, 1 x PCIe x1
