Create RAID 1 (Mirrored)

Here, we will show you how to create one Mirrored Logical Drives (LD) by using two

hard disks.

1. Select [2] from the main menu, "Dene LD Menu" appears.

2. Press [Enter], the screen appears as below.

3. Use [↓] key to select the hard disks, press [Space] key to change its assignment

status to "Y".

4. Press [Ctrl-Y] to save the setting.

[ Dene LD Menu ]

LD No RAID Mode Total Drv Capacity(GB) Status

LD 1 RAID 0

2 163.99 Functional

LD 2 −−−− −−−− −−−−−−−− −−−−

LD 3 −−−− −−−− −−−−−−−− −−−−

LD 4 −−−− −−−− −−−−−−−− −−−−

LD 5 −−−− −−−− −−−−−−−− −−−−

LD 6 −−−− −−−− −−−−−−−− −−−−

LD 7 −−−− −−−− −−−−−−−− −−−−

LD 8 −−−− −−−− −−−−−−−− −−−−

LD 9 −−−− −−−− −−−−−−−− −−−−

LD10 −−−− −−−− −−−−−−−− −−−−

[↑] Up [↓] Down [ESC] Exit [Enter] Select

[ Keys Available ]

LD 1 −−−− −−−− −−−−−−−− −−−−

[ Dene LD Menu ]

LD No RAID Mode Total Drv

LD 1 RAID 1 2

Stripe Block: NA Fast Init: ON

Gigabyte Boundary: ON Cache Mode: WriteThru

Channel :ID Drive Model Compatibilities Capacity(GB) Assignment

1 :Mas HDS728090PLA380 SATA 3G 82.34 N

2 :Mas WDC WD1200JD-98HBB0 SATA 1.5G 120.03 N

3 :Mas Hitachi HDT725025VLA3 SATA 3G 250.05 Y

4 :Mas ST3320620AS SATA 1.5G 320.07 Y

[↑] Up [↓] Down [ESC] Exit [Space] Change [Crtl-Y] SAVE [PgUp/Dn] Page Change

[ Keys Available ]

[ Dene LD Menu ]

[ Drives Assignment ]

Y

Foxconn A74ML 3.0 Series User Manual
