5-2 RAID Enable in BIOS

1. Enter the BIOS setup by pressing <DEL> key when boot up.

2. Select the “Integrated Peripherals” from the “Main menu”, then select the “IDE

Conguration” menu and press <Enter> to go to the conguration items.

3. Enable RAID function and individual SATA port for hard drive or DVD connection.

4. Press <F10> to save the setting then PC will reboot itself.

5-3 Select a RAID Array for Use

When BIOS is restarted, it will display a message asking you to press [Ctrl-F] key to

enter the main menu of FastBuild BIOS. Press [Ctrl-F], the Main Menu appears.

View Drive Assignment. . . . . . . [ 1 ]

Define LD . . . . . . . . . . . . . . . . . [ 2 ]

Delete LD . . . . . . . . . . . . . . . . . [ 3 ]

Controller Configuration . . . . . . [ 4 ]

[ Main Menu ]

Press 1..4 to Select Option [ESC] Exit

[ Keys Available ]

IDE Conguration

Help Item

OnBoard PCI IDE Controller

[Enabled]

OnChip SATA Channel

[Enabled] I Native IDE

OnChip SATA Type

[RAID] RAID

AHCI

Legacy IDE

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[RAID]

Options
