Foxconn A74ML 3.0 Series User Manual

3
27
► Spread Spectrum
If you enabled this function, it can signicantly reduce the EMI (Electromagnetic Interference)
generated by the system, so to comply with FCC regulation. But if overclocking is activated,
you had better disable it.
Voltage Options
► CPU Voltage Control
This option is used to change the CPU voltage in a step of 25mV. The voltage can be
incremented from 25mV to 350mV.
► DRAM Voltage Control
This option is used to change the DRAM voltage in a step of 0.1V. The voltage can be
incremented from 1.6V to 1.9V.
.
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
Voltage Options
CPU Voltage Control [Disabled] Help Item
DRAM Voltage Control [Disabled]
Disabled
+25mV
+50mV
+75mV
+100mV
+125mV
+150mV
+175mV
+200mV
+225mV
+250mV
+275mV
+300mV
+325mV
+350mV
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Disabled]
Options

Foxconn A74ML 3.0 Series Specifications

General

Form Factor	Micro ATX
Memory Type	DDR3
Memory Slots	2 x DIMM
Maximum Memory	8 GB
Storage Interface	4 x SATA 3Gb/s
PS/2	1 x PS/2 Keyboard, 1 x PS/2 Mouse
Video Ports	1 x VGA
Dimensions	244mm x 244mm
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	Realtek ALC662 6-channel HD Audio
LAN	10/100 Ethernet
Power Pin	24-pin ATX, 4-pin ATX 12V
Expansion Slots	1 x PCIe x16, 1 x PCIe x1
