Example 2. Reset a RAID5 system
1. A TryRAID5 volume was built with three hard disks, we want to reset one of them.
Select “3. Reset Disks to Non-RAID” in main menu and press <Enter>.
2. A warning message is displayed.
3. Select "Port 4 - ST3320620SV" hard disk as the one to be reset. Press <Enter>.
A double conrmation message pops out, press <Y> to conrm.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
3. Delete RAID Volume 4. Exit
RAID Volume : * = Data is Encrypted
ID Name Level Stripe Size Status Bootable
0 TryRAID0 RAID0(Stripe) 128KB 465.8GB
Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB
Non-RAID Disk
2 Maxtor 6L250S0 L50SKP4G 232.9GB
Non-RAID Disk
4 ST3320620SV 9QF4YJGQ 298.1GB
Non-RAID Disk
5 ST3300831AS 3NF02XH2 279.5GB
Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Matrix Storage Manager option ROM v8.0.0.1039 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
[ DISK/VOLUME INFORMATION ]
Resetting RAID disk will remove its RAID structures
and revert it to a non-RAID disk.
WARNING: Resetting a disk causes all data on the disk to be lost.
Port Drive Model Serial # Size Status
2 Maxtor 6L250S0 L50SKP4G 232.9GB Member Disk
►4 ST3320620SV 9QF4YJGQ 298.1GB Member Disk
5 ST3300831AS 3NF02XH2 279.5GB
Member Disk
Are you sure you want to reset RAID data on selected disks? (Y/N):
[↑↓]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete
[ RESET RAID DATA ]
4 ST3320620SV 9QF4YJGQ 298.1GB Member Disk
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 4. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
0 TryRAID5 RAID5(Parity) 64KB 465.8GB
Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB
Non-RAID Disk
2 Maxtor 6L250S0 L50SKP4G 232.9GB
Member Disk(0)
4 ST3320620SV 9QF4YJGQ 298.1GB
Member Disk(0)
5 ST3300831AS 3NF02XH2 279.5GB
Member Disk(0)
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Matrix Storage Manager option ROM v8.0.0.1039 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
3. Reset Disks to Non-RAID
