Enter BIOS Setup
The BIOS is the communication bridge between hardware and software, correctly setting up the
BIOS parameters is critical to maintain optimal system performance. Power on the computer,
when the message "Press TAB to show POST screen, DEL to enter SETUP" appears at the
bottom of the screen, you can press <Del> key to enter SETUP.
Main Menu
The main menu allows you to select from a list of setup functions together with two exit choices.
Use the arrow keys to select a specic item and press <Enter> to go to the submenu.
Each item in the main menu is explained below:
► Standard CMOS Features
It displays the basic system conguration, such as system date, time and oppy drive. They all
can be set up through this menu.
► Boot Setting Conguration
The boot up settings and advanced system features can be set up through this menu.
► Advanced Chipset Features
The values for the chipset can be changed through this menu, such as PCIe lane settings.
► Integrated Peripherals
All onboard peripherals can be set up through this menu.There are IDE devices, Audio, USB,
Ethernet etc...
► Power Management Setup
All the items related with Green function features can be set up through this menu.
► PnP/PCI Congurations
Phoenix - AwardBIOS CMOS Setup Utility
► Standard CMOS Features
► Quantum BIOS
► Boot Setting Conguration ► Board Information
► Advanced Chipset Features Load Optimized Defaults
► Integrated Peripherals Set Supervisor Password
► Power Management Setup
Set User Password
► PnP/PCI Congurations Save & Exit Setup
► Hardware Monitor Exit Without Saving
Esc : Quit ↑↓→← : Select Item
F10 : Save & Exit Setup
Time, Date, Hard Disk Type...
► Standard CMOS Features
We do not suggest that you change the default values in the BIOS Setup, and we shall
not be responsible for any damage which resulted from the change you made.
C
A
U
T
I
O
N
!
