Quantum BIOS
► CPU Features / Memory Settings / All Voltage Settings / OC Gear
Press <Enter> to go to each submenu.
► CPU Turbo
Intel Turbo mode support, this item will take active after PPM item is enabled.
► System Turbo
Choose over clock disable or over clock by manually.
Note: Only supports unlocked CPU; Some stepping of Core i7 engineering samples do not
support QPI Multiplier, Uncore Multiplier and Memory Bus Multiplier adjusting function.
****** Clockspeed Control Center ******
► CPU Bclock (FSB)
When "System Turbo" is set to "Enabled", this item allows you to adjust CPU FSB clock by
1MHz by step by step.
► QPI Link Fast Mode
When "System Turbo" is set to "Enabled", this item allows you to enable or disable QPI link
fast mode.
► QPI Multiplier
When "System Turbo" is set to "Enabled", this item allows you to adjust QPI multiplier. Con-
guration options are: Auto, x18, x22, x24.
► QPI Target Speed
This item shows QPI target speed.
► CPU Core Multiplier
When "System Turbo" is set to "Enabled", this item allows you to adjust CPU core multiplier.
Conguration options are: the Min is 12, the Max is 22.
► CPU Core Target Speed
This item shows CPU core target speed.
► CPU Uncore Multiplier
When "System Turbo" is set to "Enabled", this item allows you to adjust CPU uncore multiplier.
Conguration options are: Auto, from 12 to 32 by 2 step.
Phoenix - AwardBIOS CMOS Setup Utility
Quantum BIOS
► CPU Features Press Enter Item Help
► Memory Settings
Press Enter
► All Voltage Settings
Press Enter Menu Level ►
► OC Gear
Press Enter
CPU Turbo
Enabled
System Turbo Disabled
******* Clockspeed Control Center *******
x CPU Bclock (FSB) 133MHz
x QPI Link Fast Mode
Enabled
x QPI Multiplier
Auto
QPI Target Speed
2400MHz (4.8GT/s)
x CPU Core Multiplier
x22
CPU Core Target Speed
2933MHz
x CPU Uncore Multiplier Auto
CPU Uncore Target Speed
2133MHz
x Memory Bus Multiplier Auto
Memory Bus Target Speed
800MHz (DDR3 800)
x CPU Clock Skew 0ps
x IOH Clock Skew 0ps
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F7:Optimized Defaults
Press Enter
