All Voltage Settings
Note: When “System Turbo“ in “Quantum BIOS“ is set to “Enabled“, the following items are valid.
*********** CPU Voltages ***********
► CPU Core Voltage
This item is used to set CPU Core Voltage. The maximum voltage available for adjustment is
1260mV, one step is 10mV.
Warning: Adjusting the "Target CPU Voltage" beyond the default CPU voltage could result in
damage to the CPU.
► CPU Target Core Voltage
This item shows the CPU target core voltage.
► CPU Vdroop Compensation
Warning: Adjusting this item to Enabled could result in damage to the board.
► CPU VTT (UnCore) Voltage
This item is used to set CPU VTT Voltage. The maximum voltage available for adjustment is
1260mV, one step is 20mV.
Warning: Adjusting the voltage beyond the CPU VTT default voltage could result in damage to
the CPU.
► 1.8V PLL Voltage Setting
This item is used to set CPU PLL Voltage. Isolated power for QPI PLL, default voltage is 1.8V.
Warning: Adjusting the voltage beyond the QPI default voltage could result in damage to the
board.
► CPU Clock Amplitude Ctrl
CPU differential output amplitude control, default value is 800mV, may help FSB O.C.
********* Memory Voltages *********
► DRAM Voltage
The maximum voltage available for adjustment is 2.86V.
Warning: Adjusting the voltage beyond the memories default voltage could result in damage to
the memory controller, the default voltage is 1.60V
Phoenix - AwardBIOS CMOS Setup Utility
All Voltage Settings
*********** CPU Voltages *********** Item Help
x CPU Core Voltage Default
CPU Target Core Voltage 1.08750
Menu Level ►
x CPU Vdroop Compensation Disabled
x CPU VTT (UnCore) Voltage Default
x 1.8V PLL Voltage Setting 1.800V
x CPU Clock Amplitude Ctrl 0.800V
********* Memory Voltages *********
x DRAM Voltage 1.60V
x DIMM1 Vref CA (Address) x 0.500
x DIMM1 Vref DQ (Data) x 0.500
x DIMM2 Vref CA (Address) x 0.500
x DIMM2 Vref DQ (Data) x 0.500
x DIMM3 Vref CA (Address) x 0.500
x DIMM3 Vref DQ (Data) x 0.500
********* Chipset Voltages *********
x X58 IOH Core Voltage 1.10V
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F7:Optimized Defaults
