Steps to Calibrate Receiver Telemetry Voltage (RX)
(1) Power on receiver through any PWM port, voltage range is from 3.6V to 10V, measuring with a multi-
meter;
(2) Let’s take an example of 6.0V; select “Standard Voltage” in RX menu, tap on “+/-” to set standard
voltage to 6.0V;
(3) Tap on “SET”, in screen it pops up “Calibrating Succeed”, receiver telemetry voltage calibrating is
finished.
Steps to Calibrate Aircraft Power Telemetry Voltage (POW)
(1) Power on receiver through POW port, voltage range is from 3.3V to 50V, measuring with a multi-meter;
(2) Let’s take an example of 25V; select “Standard Voltage” in POW menu, tap on “+/-” to set standard
voltage to 25V;
(3) Tap on “SET”, in screen it pops up “Calibrating Succeed”, aircraft power telemetry voltage calibrating is
finished.
In DA16 transmitter users can redefine DA16 receiver’s output channel in PWM mode (Channel 1-9 in
default), so that if receiver’s channel 9 is already working in SBUS or PPM mode, PWM ports 1 to 8 can still
be defined to output transmitter channels 1 to 16.
Steps to Set PWM
(1) Power on transmitter and receiver, make sure that they are linked with each other;
(2) Transmitter PWM port 1 is mapping to receiver channel 1 PWM port, transmitter PWM port 2 is mapping
to receiver channel 2 PWM port…and so on;
(3) In “PWM Settings” menu, tap on a PWM port, select your requiring channel through virtual turntable in
screen;
(4) Tap on “SET” to finish.
PWM Settings
