Page 38
1
2
• Operating Pressures:
20 PSI Minimum / 125 PSI Maximum
• Operating Temperatures:
40°F Minimum / 110°F Maximum
1.5” Piston Style MAV's (See Installation Instructions on Motorized Alternating
Valves)
Order No. V3071 • Description: MOTOR ALT VLV 1.5 NPT REV2 or
Order No. V3071BSPT • Description: MOTOR ALT VLV 1.5 BSPT REV2
Drawing No. Order No. Description
Quantity
V3071
V3071BSPT
1
V3073
MAV/NOHWBY COVER ASY
1
1
2
V3476
AM MOTOR ASY 8 FT
1
1
3
V3592
SCREW #8-1 PHPN T-25 SS
3
3
4
V3262-01
AM1.5&2ALT/2BY REDUCGEARCVRASY
1
1
5
V3110-01
AM1 DRIVE REDUCING GEAR PLAIN
3
3
6
V3264
AM2 BYPASS REDUCTION GEAR AXLE
3
3
7 V3527
SCREW 1/4-20 X 3/4 BHSCS SS
(5/32” HEX ALLEN WRENCH REQUIRED)
4 4
8
V3072
MAV/NOHWBY 1/125/15 DRIVE ASY
1
1
9
V3506-01
MAV/NOHRD 1/125/15 PISTON
1
1
10
V3074
MAV 1/125/15 STACK ASY
1
1
11
V3525-01
MAV BODY 1.5 NPT
1
N/A
12
V3525BSPT-01
MAV BODY 1.5 BSPT
N/A
1
Not Shown
V3474
AM ALT CONNECT CORD 8FT BLK
1
1
Piston Orientation 2
No
Hard Water Bypass Valve
Configurations.
Piston Orientation 1
Motorized
Alternating Valve
and
No Hard Water Bypass
Valve Configurations.
9
10
11
12
