20 Preliminar operations
20.1 Packaging removal
Remove the packaging taking care not to damage the unit. Dispose of the packaging products (wood, plastic,
cardboard) and send them to specialized collection or recycling centers (follow local regulations in force).
20.2
Inspection
All units are assembled and wired at the factory. Upon receipt of the machine, it must be inspected immediately,
carefully checking that it has not been damaged during transport or that there are no missing parts; any complaints must
be notified to the carrier and the factory or his representative within 8 days.
20.3
Positioning
The following points must be taken into account to determine the most suitable location for installing the unit
:
• Place the machine in order to guarantee an adequate air flow.
Warning: Make sure the machine is positioned so that it does not come into contact with water.
20.4
Service area
The hot air expelled by the fans must not find obstacles.
Avoid phenomena of recirculation of the hot air between suction and delivery, otherwise the performance of the
unit will deteriorate or even the normal operation will be interrupted.
Warning: The machine must not be placed in confined spaces, which do not allow adequate diffusion in the room of the
air coming from the front grill.
Warning: Do not place or hang objects on the front panel, it may cause damage to the unit.
Attenzione: La macchina è progettata per funzionare con una miscela acqua - glicole propilenico (max 30%). Tale
percentuale non va in ogni caso superata.
20.5
Generalities
Model
Power supply
V/ph/Hz
Control circuit
V/~/Hz
FACSW90 400/3~+N/50 230/1~/50
Warning:
Before any operation on the electrical section, make sure that the power supply is disconnected.
Warning: The main power supply must be protected with a differential switch.
Warning: A main switch must be present near the unit. Complete compliance with the rules concerning electrical
installations and installations must be guaranteed.
Check that the supply voltage corresponds to the nominal data of the unit (voltage, frequency) shown on the plate on
the machine.
The power connection is via a plug with a more neutral three-pole cable and earth.
Warning: Voltage fluctuations must not exceed ± 5% of the nominal value. If these tolerances are not observed, please
contact our Studio to provide adequate devices.
Warning: The power supply must comply with the quoted limits: otherwise the warranty will be void immediately.
Warning: Grounding is mandatory.
