PRIMO Instruction Manual
26
Pos.
Part No.
Description
Q.ty
1
2902010
UPPER PANEL versione BT/SD
1
2
2901220
WATER DISTRIBUTION CIRCUIT versions BT/TP
1
2
2901222
WATER DISTRIBUTION CIRCUIT version SD
1
3
2902030
PILLAR
4
3.1
6002685
SCREW TBC 4.8x19 DIN 7981 pillar fixing
32
4
2902100
WATER TANK complete assembly
1
5
2902040
SIDE PANEL
4
5.1
6002690
SCREW TBC 4.8x45 DIN 7981 side panel fixing
16
6
2901500
COOLING PAD 770x660 - 100.5
4
7
2901050
PANEL FIXING BRACKET
8
7.1
6002664
SCREW TBC 4.2x16 DIN7981 bracket fixing
32
8
2901600
MOTOR 1~ 230V 50Hz 0.75kW with cable and connector
1
8
2901605
MOTOR 1~ 230V 50Hz 1.1kW with cable and connector
1
8
2901610
MOTOR 3~ 400V 50Hz 0.75kW with cable and connector
1
8
2901615
MOTOR 3~ 400V 50Hz 1.1kW with cable and connector
1
8.1
2901080
MOTOR BRACKET
3
8.2
6001260
SCREW TE M8x30 bracket-casing fixing
6
8.3
6003053
WASHER GROWER Ø8 bracket-casing fixing
6
8.4
6003019
FLAT WASHER Ø8x16 bracket-casing fixing
6
8.5
6004004
SCREW M8 DIN 934 motor-bracket fixing
6
8.6
6004154
WASHER GROWER Ø8 DIN 127B motor-bracket fixing
6
8.7
6004127
FLAT WASHER 8.4x24 DIN 9021 motor-bracket fixing
6
9
5104021
FAN Ø620 for motor 0.75kW 50Hz versions BT/TP
1
9
5104020
FAN Ø620 for motor 1.1kW 50Hz versions BT/TP
1
9.1
6001259
SCREW TE 8x25 DIN 933 motor-fan fixing
1
9.2
6004127
WASHER 8.4x24 DIN 9021 motor-fan fixing
2
9.3
6003015
WASHER 8x40 DIN9240 motor-fan fixing
1
