PRIMO Instruction Manual
22
5.2 Technical data
FAN MOTOR
Art. No.
Model
Rated Power
Rated Current
Airflow
FR-2906220
Primo BT 230V~ 50Hz
0.75 kW
4.1 A
12000 m³/h
FR-2906221
Primo BT 230V ~ 50Hz
1.1 kW
8.2 A
16000 m³/h
FR-2906230
Primo BT 400V 3N~ 50Hz
0.75 kW
1.8 A
12000 m³/h
FR-2906231
Primo BT 400V 3N~ 50Hz
1.1 kW
2.7 A
16000 m³/h
FR-2906420
Primo SD 230V~ 50Hz
0.75 kW
4.1 A
11000 m³/h
FR-2906430
Primo SD 400V 3N~ 50Hz
0.75 kW
1.8 A
11000 m³/h
FR-2906620
Primo TP 230V~ 50Hz
0.75 kW
4.1 A
12000 m³/h
FR-2906621
Primo TP 230V~ 50Hz
1.1 kW
8.2 A
16000 m³/h
FR-2906630
Primo TP 400V 3N~ 50Hz
0.75 kW
1.8 A
12000 m³/h
FR-2906631
Primo TP 400V 3N~ 50Hz
1.1 kW
2.7 A
16000 m³/h
PUMP
Voltage
1~ 230V 50Hz
Power
W
30
Current
A
0,15
DRAIN VALVE
Voltage
1~ 230V 50Hz
Power
W
20
Current
A
0,1
Weight (without water)
75 (versions with fan)
59 (versions without fan)
Water tank capacity
15 l
Air outlet size
Square section: 695mm x 695mm (ext.)
Circular section: Ø637mm (ext.)
Protection Degree
IP55
-
Water consumption for 1000 m³/h airflow / Air temperature at outlet (calculated)
30%RH
40%RH
50%RH
60%RH
26°C
4.3 l/h 16.7°C
3.6 l/h 18.3°C
2.9 l/h 19.8°C
2.3 l/h 21.2°C
30°C
4.7 l/h 19.8°C
3.9 l/h 21.5°C
3.1 l/h 23.2°C
2.5 l/h 24.7°C
35°C
5.3 l/h 23.5°C
4.3 l/h 25.6°C
3.5 l/h 27.5°C
2.7 l/h 29.2°C
40°C
5.7 l/h 27.3°C
4.7 l/h 29.7°C
3.7 l/h 31.8°C
2.9 l/h 33.7°C
5.3 Electrical Connections
Use power cables of the appropriate cross-
section for the rated currents of the electrical
components (see section 5.2).
Ensure that the supply voltage (V, Hz) is as
stated on the data plate. Install a differential
magnetothermal switch upstream of the
equipment. Protect the motor from
overcurrents by means of a motor protector
switch with suitable electrical characteristics.
On all versions with a fan, it is possible to vary
the flow rate of air treated by the cooler by
interfacing the motor with an external speed
regulation device (inverter). For connection,
refer to the inverter's technical
documentation.
Ensure that all electrical connections have
been made according to the
instructions in this manual, are well
insulated and comply with current
regulations. Power cables must be
replaced by the manufacturer, his technical
service department or otherwise by a qualified
