RSA/HBED Count
Message Received Message Counts
RSA Level 3 2
RSA Level 2 3
RSA Level 1 7
HBED Level 3 5
HBED Level 2 1
HBED Level 1 8
Table 12.1, RSA/HBED Count
If the count reaches more than 9 occurrences an up-
arrow symbol will appear, to indicate to the driver
that the count has exceeded 9 counts. See
Fig. 12.7.
07/25/2008
TRIP ADVISORIES
237 ROLL 518 BRK
f040770
ABC DEF
A. RSA lev. 3 Count (2)
B. RSA lev. 2 Count (3)
C. RSA lev. 1 Count (7)
D. HBED lev. 3 Count (5)
E. HBED lev. 2 Count (1)
F. HBED lev. 1 Count (8)
Fig. 12.6, Trip Advisor Message Screen
07/25/2008
TRIP ADVISORIES
23 ROLL 518 BRK
f040771
A
A. RSA Lev. 1 has more than 9 counts.
Fig. 12.7, Trip Advisor Message Screen (more than 9
counts)
