Chapter 1 Overview
1.1 Introduction
FSCUT2000E is a cost-effective CNC system for laser cutting. It is based on EtherCAT bus
technology and capable of motion control, laser control, and cutting gas control. It is common used
in sheet metal, kitchen ware, lamps and such industries. This user manual is only for installation
guidance.
1.2 System Diagram
FSCUT2000E includes the bus BMC228A Control Card, the bus IO board, and the bus height
controller, among which the BMC228A control card integrates the EtherCAT master protocol
stack.
The wiring diagram of non-BLT cutting head is shown in Figure 2.
Figure 2 Wiring diagram of FSCUT4000E - non-BLT cutter
