23
-
APPENDIC
I
T4S S07 220/60/1 Tav.8/8
P.
COD. DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNG DESCRIPTION
1
M02.42223
Etichetta frontale Front label Etiquette antérieure Vorderes Schild Etiqueta anterior
2
E15.40498
Scheda pulsantiera
Pushbutton panel
card
Carte du tableau de
commande
Tastenkarte
Tarjeta caja
pulsadores
3
D05.141
Interruttore
magnetico reed
Magnetic switch Switch magnétique Magnetschalter Contacto magnético
4
E08.37283
Rele SCLD Relay SCLD Relais SCLD Relais SCLD Conectador SCLD
5
D02.061
Teleruttore
Remote control
switch
Télérupteur Fernschalter Contactor
6
D03.165
Termica
Range 10-14
Overload
Range 10-14
Thermique
Range 10-14
Thermoschutz
Range 10-14
Termal
Range 10-14
7
E09.37400
Spina porta fusibile fuse carrier pin bondon porte-fusible Sicherungsstift colada porta-fusibile
8
D03.143
Fusibile 1.6 A Fuse 1.6A Fusible 1.6A Sicherung 1.6A Fusible 1.6A
9
D03.187
Fusibile 0,63 A Fuse 0,63 A Fusible 0,63 A Sicherung 0,63 A Fusible 0,63 A
10
E08.39322
Fusibile 2 A Fuse 2 A Fusible 2 A Sicherung 2 A Fusible 2 A
11
E08.37451
Trasformatore Transformer Transformeur Umspanner Trasformador
12
E06.37259
Condensatore 25 μf Condenser 25 μf Condesateur 25 μf Kondensator 25 μf Condensador 25 μf
13
E06.37258
Condensatore
88-108 μf
Condenser
88-108 μf
Condesateur
88-108 μf
Kondensator
88-108 μf
Condensador
88-108 μf
14
E15.40496
Scheda comando Control card Carte de commande Bedienungskarte Tarjeta de mando
15
E08.38486
Fusibile 5X20 50 m A Fuse 5X20 50 m A Fusible 5X20 50 m A
Sicherung
5X20 50 m A
Fusible 5X20 50 m A
16
E06.37257
Rele Relay Relais Relais Conectador
17
E06.37220
Condensatore motore
ventilatore
Condensator fan
motor
Condensateur moteur
ventilateur
Kondensator fűr
Ventilatormotor
Condensador por
motor ventilador
18
D03.157
Trasformatore
amperometrico
AMP Transformer Transformateur AMP Amp Transformator Transformador amp
-
E13.38654
Cavo scheda
pulsantiera
Wiring pushbutton
panel card
Cable carte du
tableau de
commande
Tastenkarte-Kabel
Cablo tarjeta caja
pulsadores
