Frigomat T4S - Page 220

29
-
APPENDIC
I
T5S S04 Tav.3/6
P. COD.
DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNG DESCRIPTION
1
B04.203
Assieme supporto Support assy Support compl. Halter kompl. Conjunto soporte
2
P11.055
Anello di tenuta Seal ring Joint Dichtung
Arandela de
sujeccion
3
B14.047
Cuscinetto Bearing Galet Rolle Cojinete
4
B10.433
Anello per cuscinetto Bearing ring Bague de galet Rollenring
Arandela de
sujeccion
5
V14.064
Anello elastico Snapring Anneau ressort Haltering Arandela elastica
6
B14.047
Cuscinetto Bearing Galet Rolle Cojinete
7
V14.065
Anello elastico Snapring Anneau ressort Haltering Arandela elastica
8
B04.205
Mozzo Hub Moyeu Nabe Eje
9
E01.37478
Motore
230/50/1
Motor
230/50/1
Moteur
230/50/1
Motor
230/50/1
Motor
230/50/1
E01.38401
Motore
220/60/1
Motor
220/60/1
Moteur
220/60/1
Motor
220/60/1
Motor
220/60/1
-
E06.37706
Condensatore marcia Running condenser
Condensateur de
roulement
Laufkondensator Condensator
-
E06.37708
Condensatore
avviamento
Start condenser
Condensateur de
démarrage
Start Kondensator Condensator
-
E06.37707
Relè Relay Relais Relais Conectador
10
B02.135
Puleggia conduttrice Guide pulley Poulie de condite Geführte Rolle Polea conductora
11
B02.143
Puleggia condotta Guided pulley Poulie conduite Geführte Rolle Polea conducta
12
P01.061
Cinghia Belt Courroie Riemen Correa
13
B03.038
Tendicinghia Belt tightener Tendeur de courroie Riemenspanner Soporte correa
14
B03.037
Rullo tendicinghia Belt-tightener bearing Galet de tendeur Spannerolle Cojinete correa
15
B04.188
Corpo supporto Body Corp du support Gehäuse Cuerpo suporte
