Froling TX 150 - Blowing in Pellets for an Empty Store with Stirrer

Operating the system
Filling/ refilling the store with fuel
Page 24
B 067 03 11_en v
3
3.2.5 Blowing in pellets for an empty store with stirrer
 CAUTION! If the head of the stirrer is already free of material
and the arms / spring blades are extended, then the feeder
unit must be active during the filling process, however the
boiler must be in “OFF” status.
 Switch off the boiler using the standby key ( ) and switch off main
switch
 Switch off main switch of expension switch cabinet (if available)
 Put residual fuel (corners, walls) in the storage room onto the top of
the outfeeder-system
 Take care to the instructions for working in the fuel storage room
 See notes in the access area of the storage room
After working in the storage room:
 Switch on main switch of the boiler and the expension switch cabinet
(if available)
 Press and hold the party key ( )for 5 seconds
 “Extra heating” mode is activated
 Wait until the arms / spring blades are touching the head of the
stirrer (about 2 turns)
 Switch off the boiler using the standby key ( ) and allow it to cool
down for at least two hours.
 Close all openings to the store to seal out dust
 Blow the fuel into the store
If the storage room is completely empty and there is no residual fuel:
 Contact Froling before filling the store
