6-2 T6-6-10010
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
33 T6-6-30050 Motor (M1, For 1PH, 100V) 1
T6-6-30051 Motor (M1, For 1PH, 110V) 1
T6-6-30052 Motor (M1, For 1PH, 240V) 1
T6-6-30060 Motor (M1, For 1PH, 220V) 1
T6-6-10442 Motor (M1, For 3PH) 1
35 T6-6-30053 Motor (M2, For 1PH, 100V) 1
T6-6-30054 Motor (M2, For 1PH, 110V) 1
T6-6-30055 Motor (M2, For 1PH, 240V) 1
T6-6-30070 Motor (M2, For 1PH, 220V) 1
T6-6-10442 Motor (M2, For 3PH) 1
38 T6-6-40011 Main Power Switch 1
42 TF-024 Transformer Cover 1
44 T6-6-10540 Bracket (For 1PH M2 Fan) 2
45 T6-6-10550 Fan (For M1/M2 Motor, 110V/1PH) 2
T6-6-10551 Fan (For M1/M2 Motor, 220V/230V/ 2
240V/1PH)
53 HBS0510 HBS, M5x10 2
55 PMS0410 PMS, M4x10 2
56 HSS0610 HSS, M6x10 4
58 HBS0620 HBS, M6x20 8
59 TMS0308 TMS, M3x8 4
61 TMS0408 TMS, M4x8 13
62 TMS0508 TMS, M5x8 6
66 HN06 HN, M6 8
70 PW06C PW, M6 (C) 16
72 PW05 PW, M5 2
73 SW04 SW, M4 2
74 SW05 SW, M5 2
75 SW06 SW, M6 8
ELECTRIC CONTROL GROUP
(For TP-601L1 / TP-601L3)
-82-
