Fromm TP-601D1 - Page 144

7-4-1 ELECTRIC CONTROL GROUP T6-8-20006
(For TP-601L1) T6-8-20007
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
29 T6-8-20481 Wire Ass'y X5 (For Motor M5-1) 1
30 T7-6-10810 Proximity Sensor (For LS6, SFS) 2 SEE PAGE 5
31 T7-1-20350 Photo Eye (PH1) 1 SEE PAGE 17
32 T6-8-20511 Wire Ass'y X8 (For Control Panel) 1
33 T6-8-20432 CPU 1
34 T6-8-20523
Wire Ass'y X9 (For LS4/LS5/Foot Switch)
1
35 T6-8-20531 Wire Ass'y X10 (For T1) 1
36 T7-6-10790 Proximity Sensor (For LS2, LS3) 2 SEE PAGE 2
37 T7-5-42660 Nut 2 SEE PAGE 17
38 T6-8-20561
Wire Ass'y X13 (For Weld Cooling Time)
1
39 T6-8-20571 Wire Ass'y X14 (For BRK) 1
40 T6-8-21690 Bridge Rectifier (BR5002) 1
41 T6-8-20580 Earth Plate (4P) 1
42 MV-6-10030 Transformer (Control)(For 110V) 1
MV-6-10031 Transformer (Control)(For 220V) 1
50 TMS0408 TMS, M4x8 4
51 TMS0412 TMS, M4x12 1
52 PMS0420 PMS, M4x20 1
53 PMS0310 PMS, M3x10 2 SEE PAGE 5
54 PMS0320 PMS, M3x20 4 SEE PAGE 2
55 PMS0325 PMS, M3x25 2 SEE PAGE 5
56 PW04 PW, M4 2
60 SW03 SW, M3 8
SEE PAGE 2, 5
