Fromm TP-601D1 - Page 149

ELECTRIC GROUP
-103-
7-6 T6-8-30002
(For TP-601L)
REF.
NO.
PART NO. DESCRIPTION REMARKS
Q'TY
2
3
4
5
10
1
T6-6-40015
T6-6-40016
T6-6-10301
T5-4-10222
T5-4-10232
T6-8-40180
Push Button Switch (Start, Reset)
2 P. Selector Switch
Start Switch With Lamp
Knob ( 6)∮
Variable Resistor (5K) ( 6)∮
Lamp
1
1
1
1
1
1
1
1
6
T6-8-30110 Control Panel
1
7
LA-10030 Label
01/2008
21 4
TMS, M5x8TMS0508
SEE PAGE 63
01/10/08
