3-3 ACCUMULATOR BOX GROUP T6-3-30002
(For TP-601L) T6-3-30003
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
14 T6-3-30140 Lower Guide (For 9mm) 1
T6-3-30140S Lower Guide (For 9mm) 1
(Stainless Steel Model)
T6-3-30141 Lower Guide (For 12mm) 1
T6-3-30141S Lower Guide (For 12mm) 1
(Stainless Steel Model)
15 T7-3-20101 Assistant Roller Ass'y (For 9mm) 1
T7-3-20102 Assistant Roller Ass'y (For 12mm) 1
16 T6-3-30160 Balance Bar (For 9mm) 1
T6-3-30161 Balance Bar (For 12mm) 1
17 T6-3-30170 Control Lever (For 9mm) 1
T6-3-30171 Control Lever (For 12mm) 1
18 T6-3-30180 Pusher 1
19 T6-3-30190 Enclosed Plate (For 9mm) 1
T6-3-30191 Enclosed Plate (For 12mm) 1
21 T6-1-61211 Motor (M5-1) 2
22 T6-1-72140 Spring 1
23 T6-3-10200 Twist Stopper 2
24 T7-1-20120 Spring 1
25 T7-1-20130 Collar 1
26 T7-5-20210 Grommet 1
27 T7-3-10132 Strap Guide (For 9mm) 1
T7-3-10133 Strap Guide (For 12mm) 1
28 T7-3-10150 Shaft 1
T7-3-10150S Shaft (Stainless Steel Model) 1
29 T7-3-10170 Bracket 1
30 T7-3-10180 Tube 1
31 T7-3-10190 Support 1
32 T7-3-10200 Sensor Lever 1
33 T7-3-10210 Bracket 1
34 T7-3-20110 Motor Support 1
35 T7-3-20150 Shaft 1
36 T7-3-20162 Assistant Roller (For 9mm) 1
T7-3-20163 Assistant Roller (For 12mm) 1
37 T7-3-20170 Accumulator Main Roller 1
-46-
02/27/08
