60 % d.c.
2)
350 A
100% d.c.
2)
290 A
Welding voltage range according to standard characteristic
MIG/MAG 14.2 - 34.0 V
Rod electrode 20.4 - 36.0 V
Max. welding voltage -
Open circuit voltage 90 V
Degree of protection IP 23
Type of cooling AF
Insulation class F
EMC emission class A
Marks of conformity CE, CSA
Safety symbol S
Dimensions l x w x h 625 x 290 x 705 mm
24.61 x 11.42 x 27.76 in.
Weight 56.0 kg
123.46 lb.
1)
connected to public grid at 230/400 V and 50 Hz
2)
d.c. = Duty cycle
203
EN
