No. Function
(1) Feeder inching button
for feeding the wire electrode into the torch‑hosepack without any flow of gas
or current
For information on the various wire feed sequences that are possible when the
welder presses and holds the "Feeder inching" button, see the Fdi parameter
in the Setup menu.
(2) Parameter selection button
for selecting the following parameters:
Sheet thickness
Sheet thickness in mm or in.
Welding current
Welding current in A
Before the start of welding, the machine automatically displays a
standard value based on the programmed parameters. During weld-
ing, the actual value is displayed.
Wire feed speed
Wire feed speed in m/min or ipm.
Welding voltage
Welding voltage in V
Before the start of welding, the machine automatically displays a
standard value based on the programmed parameters. During weld-
ing, the actual value is displayed.
If one parameter is selected, then the synergic function means that all other
parameters are automatically set as well.
(3) Left digital display
(4) Sheet thickness LED
lights up when the sheet thickness parameter is selected
(5) Welding current LED
lights up when the welding current parameter is selected
(6) Wire feed speed LED
lights up when the wire feed speed parameter is selected
(7) Overtemperature indicator
lights up if the power source overheats (e.g. because the duty cycle has been
exceeded). For more information on this, see the "Troubleshooting" section.
(8) HOLD indicator
every time a welding operation finishes, the actual values for welding current
and welding voltage are stored, and the HOLD indicator lights up.
(9) Right digital display
(10) Welding voltage LED
lights up when the welding voltage parameter is selected
(11) Mode button
for selecting the mode
2-step mode
4-step mode
Special 4-step mode (aluminium welding start-up)
When a mode is selected, the LED behind the relevant symbol lights up.
35
EN
