No. Function
(2) Parameter selection button
for selecting the following parameters:
Sheet thickness
1)
Sheet thickness in mm or in.
Welding current
1)
Welding current in A
Before the start of welding, the machine automatically displays a
standard value based on the programmed parameters. During weld-
ing, the actual value is displayed.
Wire feed speed
1)
Wire feed speed in m/min or ipm.
F1 indicator
indicates that the PushPull drive is switched on
Wire-feed unit drive current-input indicator
indicates that the wire-feed unit drive is switched on
If the indicators are lit up on the parameter selection button (2) and on the
adjusting dial (18), then the indicated / selected parameter can be altered
using the adjusting dial (18).
1)
The synergic function means that if one of these parameters is selec-
ted during MIG/MAG pulse synergic welding or MIG/MAG standard
synergic welding, then all other parameters including the welding
voltage parameter are automatically set as well.
(3) F1 indicator LED
lights up when the F1 indicator parameter is selected
(4) Wire-feed unit drive current-input indicator LED
lights up when the wire-feed unit drive current-input indicator parameter is
selected
(5) Left digital display
(6) Sheet thickness LED
lights up when the sheet thickness parameter is selected
(7) Welding current LED
lights up when the welding current parameter is selected
(8) Wire feed speed LED
lights up when the wire feed speed parameter is selected
(9) Overtemperature indicator
lights up if the power source overheats (e.g. because the duty cycle has been
exceeded). For more information on this, see the "Troubleshooting" section.
(10) HOLD indicator
every time a welding operation finishes, the actual values for welding current
and welding voltage are stored, and the HOLD indicator lights up.
(11) Arc length correction LED
lights up when the arc length correction parameter is selected
(12) Droplet detachment correction/arc force dynamic correction/arc force
dynamic LED
lights up when the Droplet detachment correction/arc force dynamic
correction/arc force dynamic parameter is selected
60
