130
Protection devic-
es for all inverters
Explanation of
footnotes
1) Maximum continuous output power up to an ambient temperature of 40 °C guaran-
teed
2) The values provided are standard values. The inverter can be customized to its re-
spective country according to requirements.
3) PCC = interface to the public grid
4) Max. current from the inverter to the solar module when there is an error in the in-
verter, or when the isolation between the AC and DC wires is defective.
5) Assured by the electrical design of the inverter
6) Peak current when turning on the inverter
7) Depending on the country setup
8) Only when using standard metal bolts
When using string fuses, the polarity of each individual solar module string must be
completely correct.
DC insulation measurement integrated
DC over-voltage protection integrated
Protection against reverse polarity
8)
integrated
Manifestation of DC overload Operating point shift
RCMU integrated
DC disconnect integrated
