Fronius IG-TL 3.0 User Manual

23
Fronius IG TL Installation and Connection
Fronius IG TL
construction
Fronius IG TL main components
The inverter consists of the following main
components:
- Wall bracket with connection area
- Power stage set with data communica-
tion rack
- Housing cover
The inverter is delivered with these compo-
nents assembled.
Overview ‘Fronius IG TL Installation and Connection’ contains the following sections:
- Choosing the Location
- Connection Options and Knockouts on the Fronius IG TL
- Attaching the Wall Bracket
- Connecting the Fronius IG TL to the Public Grid (AC)
- Connecting Solar Module Strings to the Fronius IG TL (DC)
- Inserting String Fuses
- Criteria for the Proper Selection of String Fuses
- Clipping Power Stage Sets onto the Wall Bracket
