(4)(4)
(5)
(4)
Fasten ROB 3000 to top-hat rail
3
Press the bottom of the ROB 3000 up against the top-hat rail (5)
4
The retainer snaps into place
press up
Front view ROB 3000 to the top-hat rail
29
EN
