Fronius Selectiva 2040 - Page 31

1
1
Connect the fan cable to the power
module.
1
1
1
1
Connect the mains cable to the power
module with the correct polarity (see
chapter Replacing the mains cable).
1
2
1
Place the device frame on the locking
hooks and press firmly.
2
Tighten the 5x10 TX25 screw.
Tightening torque = 3 Nm
31
EN
