PARTS
OM 0408SB1174-A
42
SNOWBLOWER – SB1174
REF. DESCRIPTION QTY PART #
1 Housing 1 ---
2 Chute (including decals) 1 5RD669782
3 Knob 2 5RD657309
4 Spacer 3/8" thick x 1.25" larg. x 4.5 lg 3 5RD669178
5 Spacer 3/16" thick x 1.25" larg. x 4.5 lg 3 5RD669179
6 Retaining plate 2 5RD665935
7 Carriage bolt 1/2" NC x 1 3/4" gr.5 PTD 6 5RD0300025
8 Auger 1 5RD666271
9 Round wire lock pin 1/4" x 2" PTD 1 5RD1900006
10 Bolt hex. 1/4" NC x 1" gr.5 PTD 4 5RD0100004
11 Flat washer 1/4" (5/16" dia. hole) PTD 4 5RD1400002
12 Nylon insert locknut 1/4" NC PTD 4 5RD1000003
13 S.M.V. sign support 1 5RD668109
14 S.M.V. reflective sign 1 5RD4200029
15 Serrated flange nut 3/8" NC PTD 1 5RD0900035
16 Bushing 1 1/4" ext. x 1 7/8" lg 1 5RD668058
17 Bolt hex. 3/8" NC x 1 1/2" gr.5 PTD 5 5RD0100040
18 Lockwasher 3/8" PTD 13 5RD1200004
19 Flat washer 3/8" 1 5RD1400003
20 Fan washer 1 5RD661554
21 Fan 1 5RD668966
22 Key 3/8" x 3/8" x 2 3/4" lg 1 5RD654174
23 Driveline Series 40 1 5RD4700159
24 Driveline shield bracket 1 5RD668097
25 Hairpin 3mm x 65mm lg PTD 1 5RD1800004
26 Driveline shield 1 5RD668057
27 Bolt hex. 3/8" NC x 5" gr.5 PTD 4 5RD0100051
28 Nut hex. 3/8" NC gr.5 PTD 12 5RD0900003
29 Spacer plate 1 5RD669722
30 Shear plate 1 5RD669595
31 Oilite bushing 1 5RD4300072
32 Shearbolt 1/4"NC x 1 1/4" gr.5, incl. nut 1 5RD669596
33 Driving shaft support 1 5RD669356
34 Grease fitting 1/4" NF 2 5RD654106
35 Parking stand 1 5RD668053
36 Bolt hex. 5/16" NC x 3/4" lg gr.5 PTD 1 5RD0100018
37 Bolt hex. 1/4" NC x 1 1/4" gr. 5 PTD 1 5RD0100005
38 Nylon insert locknut 5/16 NC PTD 1 5RD1000005
39 Bushing 1.5" ext x 2 1/8" lg PTD 2 5RD668059
40 Bushing 1 1/8" ext. x 1 3/4" lg PTD 2 5RD4600045
41 Linchpin 7/16" PTD 2 5RD1900003
42 Hitch pin 7/8" x 5 1/2" lg Cat. 1 2 5RD654196
43 Chain #60 x 78 links 1 5RD654009
